Type | Series | Features | ![]() |
![]() |
![]() |
![]() |
Operating Temperature Range (°C) |
Rate Voltage Range (V.D.C.) |
Capacitance Range (µF) |
Load Life (Hours) |
|
---|---|---|---|---|---|---|---|---|---|---|---|
![]() |
General Purpose | RA | For general purpose, standard size | ![]() |
-40~+85 | 6.3~100 | 0.1~22000 | 2000 | |||
-25~+85 | 160~450 | 0.47~680 | |||||||||
RK | Standard size, wide temperature range | ![]() |
-40~+105 | 6.3~100 | 0.47~15000 | 2000 | |||||
-25~+105 | 160~450 | 0.47~330 | |||||||||
RE | Standard size, wide temperature range | ![]() |
-40~+105 | 6.3~100 | 0.47~15000 | 3000 | |||||
-25~+105 | 160~450 | 1~470 | |||||||||
RM | Height 7(9)mm, wide temperature range | ![]() |
-40~+105 | 4~63 | 0.1~1000 | 1000 | |||||
RS | Height 5mm, wide temperature range | ![]() |
-40~+105 | 4~63 | 0.1~470 | 1000 | |||||
Low Leakage Current | LA | Low leakage current, standard size | ![]() |
-40~+85 | 10~100 | 1~4700 | 2000 | ||||
LK | Low lekage current, standard size, wide temperature range | ![]() |
-40~+105 | 10~50 | 0.47~330 | 1000 | |||||
LM | Low leakage current, height 7mm | ![]() |
-40~+105 | 6.3~63 | 0.1~220 | 1000 | |||||
LS | Low leakage current, height 5mm | ![]() |
-40~+105 | 4~50 | 0.1~100 | 1000 | |||||
Non-polarized | NP | Non-polarized, standard size | ![]() |
-40~+85 | 6.3~250 | 0.47~10000 | 2000 | ||||
NK | Non-polarized, standard size, wide temperature range | ![]() |
-40~+105 | 6.3~100 | 0.1~10000 | 1000 | |||||
NM | Non-polarized, height 7mm | ![]() |
-40~+85 | 6.3~63 | 0.1~220 | 1000 | |||||
NS | Non-polarized, height 5mm | ![]() |
-40~+85 | 6.3~50 | 0.1~47 | 1000 | |||||
BP | For horizontal deflection correction, bi-polarized | ![]() |
-40~+85 | 25~50 | 2.2~10 | 1000 | |||||
BH | For horizontal deflection correction, bi-polarized, wide temperature range | ![]() |
-40~+105 | 25~50 | 2.2~10 | 1000 | |||||
Low Impedance | TM | Low impedance, standard | ![]() |
![]() |
-40~+105 | 6.3~100 | 1~15000 | 2000~3000 | |||
-25~+105 | 160~450 | 22~330 | |||||||||
TN | Extremely low impedance, high reliability | ![]() |
![]() |
-40~+105 | 6.3~100 | 1~15000 | 2000~5000 | ||||
-25~+105 | 160~450 | 22~330 | |||||||||
TL | Extremely low impedance, long life | ![]() |
![]() |
-40~+105 | 6.3~63 | 0.47~18000 | 4000~10000 | ||||
High Temperature | TW | High temperature range for 125°C use | ![]() |
-40~+125 | 6.3~250 | 0.47~15000 | 2000 | ||||
High Reliability | TY | High frequency, high ripple current, low impedance, long life | ![]() |
![]() |
-40~+105 | 6.3~50 | 47~18000 | 2000~7000 | |||
TB | High ripple current, for ballast | ![]() |
-22~+105 | 160~450 | 2.2~100 | 2000~5000 | |||||
TX | High ripple current, long life assurance | ![]() |
-25~+105 | 160~450 | 2.2~330 | 5000~10000 | |||||
PL | High ripple current, for SMPS | ![]() |
-25~+105 | 400 | 33~150 | 5000 | |||||
-40~+105 | 450 | 33~150 | |||||||||
![]() |
General Purpose | SM | Snap-in terminal, standard | ![]() |
-40~+85 | 6.3~350 | 82~10000 | 2000 | |||
-25~+85 | 400~450 | 68~560 | |||||||||
SK | Snap-in terminal, wide temperature range | ![]() |
-40~+105 | 6.3~350 | 68~68000 | 2000 | |||||
-25~+105 | 400~450 | 56~470 | |||||||||
High Reliability | SP | Snap-in terminal, long life | ![]() |
-40~+85 | 16~350 | 82~68000 | 3000 | ||||
-25~+85 | 400~450 | 56~560 | |||||||||
SH | Snap-in terminal, wide temperature range, long life | ![]() |
-40~+105 | 16~350 | 100~22000 | 3000 | |||||
-25~+105 | 400~450 | 100~680 | |||||||||
Low Impedance | ST | Snap-in terminal, low impedance, long life | ![]() |
![]() |
-40~+105 | 16~100 | 220~22000 | 3000~5000 | |||
-25~+105 | 160~450 | 68~4700 |
